M08
Versatile 0.8-ton excavator perfect for urban construction and precision digging.
Introduction
Built with a mature design and dependable components for long-term operation. Standard four-post canopy provides greater rigidity and enhanced operator protection. Strong performance with lower investment costs and higher return potential. Compact body and expandable undercarriage for easy access to tight spaces and improved stability.
Specifications
Parameter | Value | Parameter | Value |
Operating Weight | 700 kg | Swing Radius | 1100 mm |
Bucket Capacity | 0.02 m³ | Max Dig Height | 2450 mm |
Overall Dim. | 2850×1050×1500 mm | Max Dump Height | 1600 mm |
Fuel Tank | 5 L | Max Dig Reach | 2450 mm |
Hydraulic Tank | 13 L | Max Dig Depth | 1300 mm |
Work Pressure | 14 MPa | Hydraulic Flow | 18 L/min |
Engine | Yanmar | Gradeability | 30° |
Key Features
CE Certified
Meets European safety standards
Fuel Efficient
Advanced engine technology
24/7 Support
Round-the-clock technical assistance
